CAPABILITIES

CNC TURNING CENTER

PUMA 6G High Speed Gang Slide
(with LNS Super Hydrobar. HS,
Automatic Bar Feeder)
Capacity:
Max. Turning Dia 6.5" / Length 6.5"
Max. Bar Work Dia: 1.50"
Spindle Speed: 35 ~ 6,000 RPM

PUMA 6S (with LNS Super Hydrobar. HS, Automatic Bar Feeder)
Capacity:
Max. Turning Dia 14.2" / Length 14.6"
Max. Bar Work Dia: 1.50"
Turret Station: 12
Spindle Speed: 6,000 RPM

PUMA 8S (with LNS Quick Load Bar Feeder)
Capacity:
Max. Turning Dia 14.2" /
Length 14.6"
Max. Bar Work Dia: 2.00"
Turret Station: 12
Spindle Speed: 5,000 RPMM

STAR SR-10J type "C" (CNC Swiss Type Automatic Lathe)
Capacity:
Max. Turning Dia: 3/8"
Main Spindle Speed: 15,000 RPM
Sub Spindle Speed: 10,000 RPM
Front/Side Milling: 10,000 RPM

CNC MILLING CENTER

YCI SUPER MAX | XV 1020A
Vertical Machining Center
Travel Axis (x,y,z): 40" x 20" x 21"
Table Size: 44" x 20"
Table Load: 1,100 lbs.
Spindle Speed: 8,000 RPM
Accuracy:
Positioning: +0.004mm(+0.00016")
Repeatability: +0.002mm(+0.00008")

KITAMURA | Mycenter 3Xi
Vertical Machining Center
Travel Axis (x,y,z): 30" x 18" x 18"
Table Size: 35" x 16"
Table Load: 1,100 lbs.
Spindle Speed: 15,000 RPM
Accuracy
Positioning: +0.003mm/full stroke(+0.00012")
Repeatability: +0.001mm(+0.00004")
Cutting: +0.008mm(0.0003) [boring]

MANUAL EQUIPMENT

BRIDGEPORT MILL 21" POWER FEED (with Anilan Digital Readout)

BRIDGEPORT MILL 21" POWER FEED (with Mitutoyo Digital Readout)

HARDINGE CHUCKER (with Auto Threader)

ROLLIN SAW

ROCKWELL Drill Presses

Tumbler and Support Equipment
